In regards to an 88GW,

Can anybody please id the part next to the red arrow (not the rust)?

I think it is some kind of body mount, it is falling apart but resembles a rubber donut.

thanks
Rob
__________________
'88 Grand Wagoneer
Reply With Quote
  #2
Old 03-05-2006, 11:36 AM
Rande's Avatar
Rande Rande is offline
Ph.D in Jeep B.S.

Join Date: Jun 26, 2000
Location: Winona, Minnesota
Posts: 5,489
Post

Don't see a thing. Pic posting problem?
__________________
N4ZYV

I ain't giving up. I've worked hard, it took me years to work my way to the bottom.


1998 Cherokee Sport (not maroon! Have history with maroon XJs)
1937 Chevy pickup (in progress)
1966 Mustang
1937 IH D2
Reply With Quote
  #3
Old 03-05-2006, 11:37 AM
david13 david13 is offline
Grease Monkey

Join Date: Oct 11, 2005
Location: ky
Posts: 274
Post

no pic or red arrow
__________________
74 cj5<br />78 wagoneer<br />86 wagoneer
Reply With Quote
  #4
Old 03-05-2006, 11:55 AM
Rob z's Avatar
Rob z Rob z is offline
Master Mechanic

Join Date: May 05, 2005
Location: Pa coal region
Posts: 923
Post


I'm not sure but.... it looks like a sign with some words on it.
__________________
89 Grand Rottweiler shuttle
Reply With Quote
  #5
Old 03-05-2006, 12:22 PM
PlumCrazy's Avatar
PlumCrazy PlumCrazy is offline
360 AMC

Join Date: Oct 07, 2003
Location: Just S. of Branson (in Beautiful Razorback Country)
Posts: 3,292
Post

Bad, bad Rob...now look ashamed!

Wayne S
Reply With Quote
  #6
Old 03-05-2006, 12:57 PM
RobM's Avatar
RobM RobM is offline
Member

Join Date: Feb 04, 2006
Location: Alexandria, VA
Posts: 115
Post

sorry - forgot picture

__________________
'88 Grand Wagoneer
Reply With Quote
  #7
Old 03-05-2006, 01:00 PM
RobM's Avatar
RobM RobM is offline
Member

Join Date: Feb 04, 2006
Location: Alexandria, VA
Posts: 115
Post

hope this works
__________________
'88 Grand Wagoneer
Reply With Quote
  #8
Old 03-05-2006, 02:58 PM
FSJ Guy FSJ Guy is offline

Join Date: Mar 20, 2005
Location: Colorado
Posts: 10,061
Post

Yup, it's a body mount. Unless it falls out or you carry heavy loads in the rear, I wouldn't be too concerned about it.
__________________
Ethan Brady
1987 Grand Wagoneer, slightly longer than stock.

www.bigscaryjeep.com

Don't mess with me. I once killed a living hinge.
Reply With Quote
  #9
Old 03-05-2006, 03:12 PM
Lazarus's Avatar
Lazarus Lazarus is offline
Gear Head

Join Date: Apr 12, 2004
Location: Dahlonega GA
Posts: 667
Post

yep, rear body mount...frame is rusted away from the mount...same on mine and many others...might be a bad thing in a wreck or a side hill but other than that its just a bug...
__________________
* A NEW LIFE, A NEW CHALLENGE...EVERY ROCK,HILL, AND BOGGIN HOLE OR BUST... new plans for my rigs, the 74 j truck is getting sold, the 89 wag is a temporary parts rig, and my new to me 85 J10 is getting all the attention... 36" IROKs and a punched out 401 coming its way...
Reply With Quote
  #10
Old 03-20-2007, 07:59 AM
Tad's Avatar
Tad Tad is offline

Join Date: Nov 30, 2001
Location: Out West
Posts: 17,617
I see what you are talking about now.
Be a PITA but I think you could just weld a new piece in there with the correct size hole in the correct location.
Probably be harder to get the mount off than do the sizing & welding.
__________________
2000 Infinity QX4, 3.3L, MPFI, 4 speed auto, 2 speed Nissan tcase, Unibody, IFS front, 4 link rear solid axle with 255-70/16s

IFSJA WMS PROJECT
EARLY WAG LIFT SEARCH

Quote:
...Pay no attention to these heathen barbarians with their cutting torches and 8" lift kits!...

Self Inflicted Flesh Wound
Reply With Quote
  #11
Old 03-20-2007, 11:03 AM
Dr Teeth Dr Teeth is offline
Grease Monkey

Join Date: Nov 14, 2006
Location: Redding, California
Posts: 381
If it's like my '71 (and I think it is) you'd have to take the rear bumper completely off (should be able to grind off bolts if needed) and then that rear crossmember of the frame can be unbolted from the frame. On mine there where six bolts on each frame rail (two facing out, two on bottom, two on top). Considering the rust none of them will probably come out freely and all can be easily ground off except the two on the tops of the framerails on each side. Would have to get a nut splitter in there, or maybe a sawzall? Not sure as it's pretty tight with the bodywork in the back. I just trimmed up the body panels in the rear to improve the access, but that's not a fix for everybody.

Todd
Reply With Quote
  #12
Old 03-20-2007, 12:54 PM
yankeedog yankeedog is offline
Bleedin' Gasoline

Join Date: Mar 14, 2007
Location: long island new york
Posts: 1,621
Yup body mount.eventually the body will start to droop if it hasnt done it already.not the end of the world .my body started to droop when i hit 40. new i guy once who fixed a problem like that with a piece of pressure treated lumber and one or two carriage bolts.it squeaked a little.but it worked.
