Well...that don't give me a warm fuzzy feeling. *Updated*

pulled the motor out of the GW to put the fresh tranny in,and to find an evasive oil leak,and put the baffle on the bottom of the intake manifold. i also decided to pull the heads and see how the cylinders were looking.

looks like the pistons were a little tight in the bores to me.





those scores can be seen but not felt. but the oil film barrier was definitely broken. 180 degrees from the pin,looks like it got tight right below the rings.

oh,found the leak too. the plug on the right.




will be loading this up later today and swinging by the machine shop for a visit tomorrow.
__________________
Quote:
Originally Posted by Hankrod
Ristows right.................again,




Quote:
Originally Posted by Fasts79Chief
... like the little 'you know what's' that you are.




Quote:
Originally Posted by Fasts79Chief
I LOVE how Ristow has stolen my comment about him ... "Quoted" it ... and made himself famous for being an ***hole to people. Hahahahahahahahahha!


→ Where the kids hang out...

fsjbuilder.org come for the mindless chat,stay for the hand drawn emoticons.

It's like you're unraveling a big cable-knit sweater that someone keeps knitting...and knitting...and knitting...and knitting...

Last edited by Ristow : 09-19-2009 at 06:45 PM.
Reply With Quote
  #2
Old 07-12-2009, 08:49 AM
bigun's Avatar
bigun bigun is offline

Join Date: Feb 10, 2003
Location: Back in Mountainair NM
Posts: 20,085
You didn't check the ring gaps before you put it together?
__________________
charlie
KB0HXA
"Crom" 76/75 Cherokee/J20 Hybred,

Quote:
Originally Posted by Gambler68
congrats...that's the first post on here I have absolutely no effing clue how to comment on.


How you behave toward cats here below determines your status in Heaven.
Robert A. Heinlein
The birth of CROM is recorded here
http://www.alaska4x4network.com/showthread.php?t=7778
Reply With Quote
  #3
Old 07-12-2009, 08:52 AM
Ristow Ristow is offline

Join Date: Jan 20, 2006
Location: The Great Googley Moogley Midwest.
Posts: 17,047
Quote:
Originally Posted by bigun
You didn't check the ring gaps before you put it together?

of course i did. i fit the rings. that aint ring scoring,that's piston scoring.
__________________
Quote:
Originally Posted by Hankrod
Ristows right.................again,




Quote:
Originally Posted by Fasts79Chief
... like the little 'you know what's' that you are.




Quote:
Originally Posted by Fasts79Chief
I LOVE how Ristow has stolen my comment about him ... "Quoted" it ... and made himself famous for being an ***hole to people. Hahahahahahahahahha!


→ Where the kids hang out...

fsjbuilder.org come for the mindless chat,stay for the hand drawn emoticons.

It's like you're unraveling a big cable-knit sweater that someone keeps knitting...and knitting...and knitting...and knitting...
Reply With Quote
  #4
Old 07-12-2009, 10:12 AM
jeepguzzi jeepguzzi is offline
FSJ Maniac

Join Date: Oct 21, 2000
Location: bensenville, illinois, usa
Posts: 4,012
Maybe those aren't AMC 360 pistons. Maybe they are Dodge 360 pistons.

We once took a straight 6 Ford motor to the machinist for a rebuild. He pulled out pistons from a 400 V8 or something.
__________________
79Cherokee Chief<br />4\" BDS Lift<br />Custom Bumper <br />33\"x 11.5\" x 15\" BFG All-Terrains"<br /> T.H. 400 B.W.1339 Quadra Trac <br />Mile marker 16% O.D.part time kit<br />360c.i. Edelbrock pkg.<br />MSD ign. & coil <br/>Bored .030 over<br />Tri-Y headers<br />stainless steel exhaust<br />mustang seats<br />Holley 4bbl
Reply With Quote
  #5
Old 07-12-2009, 10:44 AM
NVJEEPER's Avatar
NVJEEPER NVJEEPER is offline
Gear Head

Join Date: Feb 24, 2006
Location: Eagle Valley,Nv.
Posts: 641
Oh man, is that the roller rocker'd engine? Cool find on the oil leak!
__________________
Damon
'85 Grand Wagoneer
Reply With Quote
  #6
Old 07-13-2009, 04:06 AM
Ristow Ristow is offline

Join Date: Jan 20, 2006
Location: The Great Googley Moogley Midwest.
Posts: 17,047
wiseco pistons. yah,it's the roller rocker engine.
__________________
Quote:
Originally Posted by Hankrod
Ristows right.................again,




Quote:
Originally Posted by Fasts79Chief
... like the little 'you know what's' that you are.




Quote:
Originally Posted by Fasts79Chief
I LOVE how Ristow has stolen my comment about him ... "Quoted" it ... and made himself famous for being an ***hole to people. Hahahahahahahahahha!


→ Where the kids hang out...

fsjbuilder.org come for the mindless chat,stay for the hand drawn emoticons.

It's like you're unraveling a big cable-knit sweater that someone keeps knitting...and knitting...and knitting...and knitting...
Reply With Quote
  #7
Old 07-13-2009, 04:54 AM
lost1's Avatar
lost1 lost1 is offline
Master Mechanic

Join Date: Sep 21, 2008
Location: Bend, OR
Posts: 908
Ouch! Well it ain't warm and fuzzy, but at least it got discovered when it did.
__________________
Quote:
Originally Posted by Locked and Loaded
Jeeps don't get stuck. People do.
<══════════════════════════════>
Let the good times roll!
'83 Wagoneer«» 401/TF727/3:31 AMC20
Reply With Quote
  #8
Old 09-19-2009, 06:46 PM
Ristow Ristow is offline

Join Date: Jan 20, 2006
Location: The Great Googley Moogley Midwest.
Posts: 17,047
goin' back to the assembled side...



__________________
Quote:
Originally Posted by Hankrod
Ristows right.................again,




Quote:
Originally Posted by Fasts79Chief
... like the little 'you know what's' that you are.




Quote:
Originally Posted by Fasts79Chief
I LOVE how Ristow has stolen my comment about him ... "Quoted" it ... and made himself famous for being an ***hole to people. Hahahahahahahahahha!


→ Where the kids hang out...

fsjbuilder.org come for the mindless chat,stay for the hand drawn emoticons.

It's like you're unraveling a big cable-knit sweater that someone keeps knitting...and knitting...and knitting...and knitting...
Reply With Quote
  #9
Old 09-19-2009, 06:50 PM
PlasticBoob's Avatar
PlasticBoob PlasticBoob is offline
All Makes Combined

Join Date: Jun 30, 2003
Location: Long Beach, CA
Posts: 3,991
Man, that sucks! So how does that happen? Too hot? And what does one do to prevent it from happening again?
__________________
Rob
1974 Cherokee S, fuel injected 401, Trans-am Red, Aussie locker 'out back'
Click for video

The Southern California FSJ forum
Reply With Quote
  #10
Old 09-19-2009, 07:03 PM
Ristow Ristow is offline

Join Date: Jan 20, 2006
Location: The Great Googley Moogley Midwest.
Posts: 17,047
well....i think it's a compound problem.

i sent the pistons back to wiseco,they wanted a look at them. no signs of heat,however the pistons were spec'd incorrectly by the rather well known speed shop that "built" the kit for me. that same guy bailed on me when i got the pistons and found they were built to the early block deck height. he said it was between me and wiseco now. cost me a couple hundred to deck the block/plane the manifold. great customer service.

turns out,he spec'd a 360 piston with a 1" pin and the custom-(incorrect)- deck height. he should have discussed what my intentions were,which i covered in great detail,because Wiseco would have instead used thier standard 401 forging,and turned it down to my bore. the 401 has a rather severe rod angle. the 401 forging they use is a different alloy,and barrel shape to combat the scuffing these engines are prone to.


however,i don't think that was THE issue. the scuffing-polishing really,the markings couldn't be felt-was very inconsistent. i think what really did it was one of the mornings last winter when it was -28 degrees out,my coolant was froze up,too thick for the waterpump to push through. the engine would build up heat till it finally pushed through,at which time the engine would return to normal temp. i would have been inside drinking coffee while this was happening.


block has a fresh hone. fresh crank,bearings,rings. going to advance the cam this time too. using Hastings rings this time too,my preferred brand.
__________________
Quote:
Originally Posted by Hankrod
Ristows right.................again,




Quote:
Originally Posted by Fasts79Chief
... like the little 'you know what's' that you are.




Quote:
Originally Posted by Fasts79Chief
I LOVE how Ristow has stolen my comment about him ... "Quoted" it ... and made himself famous for being an ***hole to people. Hahahahahahahahahha!


→ Where the kids hang out...

fsjbuilder.org come for the mindless chat,stay for the hand drawn emoticons.

It's like you're unraveling a big cable-knit sweater that someone keeps knitting...and knitting...and knitting...and knitting...
Reply With Quote
  #11
Old 09-19-2009, 07:13 PM
grand_wag_85's Avatar
grand_wag_85 grand_wag_85 is offline
Murphy's Law Poster Child

Join Date: Dec 03, 2003
Posts: 10,707
What will the finished power specs be Mike?
__________________
You know it's bad when your car's on the EPA's 10 most wanted list!

'82 J10
'65 J2000

Reply With Quote
  #12
Old 09-19-2009, 07:18 PM
Ristow Ristow is offline

Join Date: Jan 20, 2006
Location: The Great Googley Moogley Midwest.
Posts: 17,047
really aint got a clue. it was a very nice engine to drive. torque right off idle,pulled nicely,even with the stock exhaust. lean into the throttle a little to pass,no need for passing gear. burned 87 octane no problem.

consistently got over 13.5 mpg's too.
__________________
Quote:
Originally Posted by Hankrod
Ristows right.................again,




Quote:
Originally Posted by Fasts79Chief
... like the little 'you know what's' that you are.




Quote:
Originally Posted by Fasts79Chief
I LOVE how Ristow has stolen my comment about him ... "Quoted" it ... and made himself famous for being an ***hole to people. Hahahahahahahahahha!


→ Where the kids hang out...

fsjbuilder.org come for the mindless chat,stay for the hand drawn emoticons.

It's like you're unraveling a big cable-knit sweater that someone keeps knitting...and knitting...and knitting...and knitting...
Reply With Quote
  #13
Old 09-19-2009, 07:28 PM
grand_wag_85's Avatar
grand_wag_85 grand_wag_85 is offline
Murphy's Law Poster Child

Join Date: Dec 03, 2003
Posts: 10,707
Dern! Well when it comes time for me to rebuild the 401 in my '76 I will be picking your brain a bit
__________________
You know it's bad when your car's on the EPA's 10 most wanted list!

'82 J10
'65 J2000

Reply With Quote
  #14
Old 09-19-2009, 10:03 PM
cu4whln's Avatar
cu4whln cu4whln is offline
350 Buick

Join Date: May 16, 2008
Location: Canton, Mi USA !
Posts: 1,047
Quote:
Originally Posted by Ristow
goin' back to the assembled side...




Jeep Porn 101 . . . yea, I like to watch !!

I frinkin' love engine in process / building shots!

Hope "round 2" works out well for you.
__________________
It's not yours 'til ya bleed on it . . .

1977 "401" 'Da Chief
1979 Chero: "Madness"
1985 CJ : Renegade -locked and loaded
2001 XJ : Driver 1998 XJ 2 door

'Da Chief here: http://www.ifsja.org/forums/vb/showt...ighlight=chief


"Madness" build here:
http://www.ifsja.org/forums/vb/showthread.php?t=89280
Reply With Quote
  #15
Old 09-20-2009, 12:38 PM
mattmopar440's Avatar
mattmopar440 mattmopar440 is offline
AMC 4 OH! 1

Join Date: May 17, 2007
Location: Algonquin (Chicago suburb) Illinois
Posts: 4,078
so you didnt have to bore it out that at least a little good news mike
__________________
91' Grand Wagoneer
401/727/229, Currently:Down for Body Work
77' Wagoneer 401 Parts rig
80's J10 258/T-5/208
89' Jeep GrandWagoneer
New Project
74' J10 Go Grabber Green Running
Quote:
Originally Posted by Heavy_Metal_Thunder_81
Inferior Chevy


Reply With Quote
  #16
Old 09-20-2009, 12:48 PM
Gambler68's Avatar
Gambler68 Gambler68 is offline
Rabble Rouser

Join Date: Feb 29, 2004
Location: Ignacio, Colorado, USA
Posts: 14,082
Good luck man. Sucks the shop bailed on ya, that's his rep now to deal with. Hope all goes smooth from here on out.
__________________
1979 Chero S "Sundog" 1979 Chero S "Hammer"
1968 327 J3000 1978 J10SWB
The Edge... there is no honest way to explain it because the only people who really know where it is are the ones who have gone over.
Hunter S. Thompson .

Reply With Quote
  #17
Old 09-20-2009, 08:22 PM
bigun's Avatar
bigun bigun is offline

Join Date: Feb 10, 2003
Location: Back in Mountainair NM
Posts: 20,085
Glad you got it worked out, sucks that the shop owner bailed on you though
__________________
charlie
KB0HXA
"Crom" 76/75 Cherokee/J20 Hybred,

Quote:
Originally Posted by Gambler68
congrats...that's the first post on here I have absolutely no effing clue how to comment on.


How you behave toward cats here below determines your status in Heaven.
Robert A. Heinlein
The birth of CROM is recorded here
http://www.alaska4x4network.com/showthread.php?t=7778
Reply With Quote
  #18
Old 09-20-2009, 10:26 PM
twisted frame twisted frame is offline
350 Buick

Join Date: Apr 01, 2003
Location: Massachusetts
Posts: 1,039
I'm just learning about inner engine problems, terminology and pretty much anything to do with the rotating assembly. I can see where you've pointed out the issue with the scoring on the piston wall and *I think* I understand what you mean when saying it's perpendicular to the wrist pin.

Is there anything else obvious in the photos that show other problems? I'm just curious. Does the fact that the oil barrier was broken only apply to the scoring on the piston wall or does that refer to the lighter-colored markings on the center of the piston too?
__________________
Mike
1973 J4000, 360 2bbl, T18, Model 20,
44, 60-2, 32x11.5x15" on 15x8" CJ wagon wheels.
Now in black primer.

Last edited by twisted frame : 09-20-2009 at 10:29 PM.
Reply With Quote
  #19
Old 09-21-2009, 03:31 PM
Ristow Ristow is offline

Join Date: Jan 20, 2006
Location: The Great Googley Moogley Midwest.
Posts: 17,047
the oil film barrier refers to the cylinder/skirt scuffing. the markings on the top of the piston are from combustion.

Quote:
I think* I understand what you mean when saying it's perpendicular to the wrist pin.

that is where pistons scuff first when they get tight,for whatever reason.it is the largest diameter area.
__________________
Quote:
Originally Posted by Hankrod
Ristows right.................again,




Quote:
Originally Posted by Fasts79Chief
... like the little 'you know what's' that you are.




Quote:
Originally Posted by Fasts79Chief
I LOVE how Ristow has stolen my comment about him ... "Quoted" it ... and made himself famous for being an ***hole to people. Hahahahahahahahahha!


→ Where the kids hang out...

fsjbuilder.org come for the mindless chat,stay for the hand drawn emoticons.

It's like you're unraveling a big cable-knit sweater that someone keeps knitting...and knitting...and knitting...and knitting...
Reply With Quote
  #20
Old 09-21-2009, 04:39 PM
mattmopar440's Avatar
mattmopar440 mattmopar440 is offline
AMC 4 OH! 1

Join Date: May 17, 2007
Location: Algonquin (Chicago suburb) Illinois
Posts: 4,078
I really looking forward to tearing into my 401 and seeing whats up .....Not but why I'm in there I'll throw some 10.0-1 pistons in there to keep up with maniac mike
__________________
91' Grand Wagoneer
401/727/229, Currently:Down for Body Work
77' Wagoneer 401 Parts rig
80's J10 258/T-5/208
89' Jeep GrandWagoneer
New Project
74' J10 Go Grabber Green Running
Quote:
Originally Posted by Heavy_Metal_Thunder_81
Inferior Chevy


Reply With Quote
Reply


Thread Tools Search this Thread
Search this Thread:

Advanced Search
Display Modes

Posting Rules
You may not post new threads
You may not post replies
You may not post attachments
You may not edit your posts

vB code is On
Smilies are On
[IMG] code is On
HTML code is Off
Forum Jump


All times are GMT -6. The time now is 05:26 PM.


Powered by vBulletin Version 3.5.4
Copyright ©2000 - 2020, Jelsoft Enterprises Ltd.
corner corner
